Alfa Laval - Pressure Gauge

Alfa Laval pressure gauges provide accurate and reliable indication of internal pressure in vessels and systems used in the dairy, food and beverage and biopharm industries.

Related Industries:

Food and beverage, Home and Personal care

Application:

The Alfa Laval pressure gauge is designed to fulfil the demands of pressure gauges in hygienic and pharmaceutical production. It is suitable as a local indicator in filtration systems, pump system pressure vessels etc. Available in two sizes. Features: Wetted parts in acid-proof, stainless steel. Measuring range -1 to 60 bar. Process temperature up to 200°C.

Standard range:

Our standard range is supplied with a liquid-filled housing. It includes an 80 mm / 100 mm diameter dial and a built-in volume compensator and relief plug. The housing is made of stainless steel (AISI 304) and the clamp connection and pressure sensor are made of stainless steel (AISI 316L). As an option, it can be delivered electropolished and with 3A, 3.1 or calibration certificates.
